New iBeLink 10.8 GH/s X11 miner

mrearthbound

Member
Feb 18, 2017
248
44
88
32
Probably a reseller that cut a deal with Bitmain. Bitmain sends them a few miners in mid September that they then resell for a mark-up. And they're saying Oct to have a buffer in case Bitmain delays...


Crypteq

New Member
Jul 5, 2017
30
2
8
43
Hi!! Now we have 9pc iBelink 10.8 in stock, who want this asic pls tell me!

Отправлено с моего Letv X910 через Tapatalk

  • Like
Reactions: ottokoester

shaninium

Member
Feb 12, 2017
39
5
48
39
Home / Blog
Posted on August 4, 2017
iBeLink DM22G for Delivery in October!

Written by
iBeLink
Posted in
Uncategorized

We are very happy to announce the next generation of iBeLink X11 miners, the DM22G which features a hash rate of 22 GH/s. High volume delivery will be in October. Interested customers are welcome to contact us for a product demonstration in China. The following are the DM22G technical specifications:

  • Hash Function: X11
  • Hash Rate: 22 GH/s ±5%
  • Power Consumption: 810 W (at the wall, with 25°C ambient temp)
  • Power Efficiency: 0.037 J/MH (at the wall, with 25°C ambient temp)
  • Number of TNB0303 chips per unit:216
  • Operating Temperature: 0 °C to 40 °C
  • Network Connection: Ethernet
  • Power Supply: 110V to 240V, 50Hz/60Hz
  • Certifications: FCC, CE
  • Dimensions: 490mm(L)*350mm(W)*180mm(H)
  • Weight: 19kg (with packing materials)


    https://ibelink.co/blog/


dashminelover

Member
Jul 17, 2017
217
30
88
56
Home / Blog
Posted on August 4, 2017
iBeLink DM22G for Delivery in October!

Written by
iBeLink
Posted in
Uncategorized

We are very happy to announce the next generation of iBeLink X11 miners, the DM22G which features a hash rate of 22 GH/s. High volume delivery will be in October. Interested customers are welcome to contact us for a product demonstration in China. The following are the DM22G technical specifications:

  • Hash Function: X11
  • Hash Rate: 22 GH/s ±5%
  • Power Consumption: 810 W (at the wall, with 25°C ambient temp)
  • Power Efficiency: 0.037 J/MH (at the wall, with 25°C ambient temp)
  • Number of TNB0303 chips per unit:216
  • Operating Temperature: 0 °C to 40 °C
  • Network Connection: Ethernet
  • Power Supply: 110V to 240V, 50Hz/60Hz
  • Certifications: FCC, CE
  • Dimensions: 490mm(L)*350mm(W)*180mm(H)
  • Weight: 19kg (with packing materials)


    https://ibelink.co/blog/
All the customers who purchased in July have not yet got delivery for iBeLink DM11G and expect that iBelink send them free upgrade kit for DM22G as those customers purchased DM11G at expensive rates by putting their trust in iBelink.

Its time for iBeLink to show to the miners that they are miner friendly and a good organization with positive intentions.

I hope iBeLink will give this FREE UPGRADE KIT porposal a consideration and win the heart of miners.

Thanks.


shaninium

Member
Feb 12, 2017
39
5
48
39
All the customers who purchased in July have not yet got delivery for iBeLink DM11G and expect that iBelink send them free upgrade kit for DM22G as those customers purchased DM11G at expensive rates by putting their trust in iBelink.

Its time for iBeLink to show to the miners that they are miner friendly and a good organization with positive intentions.

I hope iBeLink will give this FREE UPGRADE KIT porposal a consideration and win the heart of miners.

Thanks.
Ibelink dm11g in the box is 41 pounds, unless thats a shipping mistake, maybe your right cause they should weigh at least 48 pounds (22kg). These new machines are 19kg...(41~pounds). Maybe they are being shipped with the upgrade kit now..

  • Like
Reactions: dashminelover

dashminelover

Member
Jul 17, 2017
217
30
88
56
Ibelink dm11g in the box is 41 pounds, unless thats a shipping mistake, maybe your right cause they should weigh at least 48 pounds (22kg). These new machines are 19kg...(41~pounds). Maybe they are being shipped with the upgrade kit now..
If iBeLink does so they will be winning heart of miners and making all us its sincere and loyal customers


Crypteq

New Member
Jul 5, 2017
30
2
8
43
Hi guys! All our clients can update to dm22g when we have this kit in warehouse!!!
To be continued...

Отправлено с моего Letv X910 через Tapatalk


Vagnavs

New Member
Jul 13, 2017
5
2
3
41
I am unable to connect to the web interface and therefore the miner is not mining. Is there a reset on the miner or any other things that I can try to make it work? The web interface worked earlier but now it won’t open up. Your help would be greatly appreciated


ottokoester

New Member
Jul 23, 2017
11
0
1
Kassel, Germany
Yes, there is a reset. But it will put the default configuration.
Some miners comes with these problems, I suggest you to download the original image file form iBelink website and install in a extra card.
The miner is just a linux installed in a Pi Board, which has a card with a customised Linux for DASH Mining.
Remove this card (Shutdown, open de miner, remove this micro SD card and don't delete or install at this original card.)
Put your new card with the new system installed there.

Why I'm suggest this? Because without root password, you can not do better modifications and the permissions of the user miner are blocked, if you have the root password, you can try to repair and fix this problem via ssh. The question is: Can you operate Linux? If not, call someone Linux Specialist, Geek, Administrator or Friend, who knows Linux very well!

You can download the image and a separate test tool at the manufacturer iBelink (xing-ling) website:
iBeLink DM11G TF Card Image Ver. 3.5.21 (https://www.dropbox.com/s/ed7tz35gjnt4tlq/iBeLink-DM11G-Image-Ver3.5.21.rar?dl=0)
iBeLink DM11G TestTool TF Card Image Ver. 3.5.21 (https://www.dropbox.com/s/3l5bm3ct2erfx48/iBeLink-TestTool-Image-Ver3.5.21.rar?dl=0)

A second dirty solution is:

Stop the mining system at Web-Interface. Stop and deactivate all pool configurations, at the pools tab configuration.
When the complete pools are stopped, duplicate one configuration that it uses the same configuration of your pool account configuration.
Set as default and delete the others, one by one. Sometimes it will freeze when you try to do this. I don't know why, but after a patience action, has worked with me. Anyway, the best is to install a complete new image, because some miners, theoretically, could be hacked, if you don't have a root or administrator password. Welcome to the club! I wish you the best!!!

PS: Don't believe at people offers you expensive and fast solutions, listen you mind, feel your heart and use your life experience, fly to China and make new Chinese friends there, it's the best way to understand and acquire miners with a real price and real knowledge.




I am unable to connect to the web interface and therefore the miner is not mining. Is there a reset on the miner or any other things that I can try to make it work? The web interface worked earlier but now it won’t open up. Your help would be greatly appreciated


Vagnavs

New Member
Jul 13, 2017
5
2
3
41
Just to clarify the web Interface won't come up at all. I think the IP configuration Is incorrect. So I'm not able to do any reset, reboot or other options in the web interface




If anybody could lead some help that would be great. Would be willing to pay to get this figured out and working
[[[/QUOTE]


Last edited:

iBeLink_1

Active Member
Feb 17, 2016
382
65
98
Hi,
Double check that the network cables inside the miner is securely connected. If everything is good and you are still not able to find the IP address, it sounds like a corrupted sd card. You will need to re-image it with the file mentioned in ottokoester's post above.


ottokoester

New Member
Jul 23, 2017
11
0
1
Kassel, Germany
Hi Vagnavs,

Can you look at your router?

If you have a new IP-Address on your network, you can access you iBelink with this IP at the browser.

I can help you, but you need a webcam, we need to look inside the hardware case and if the problem persist you need a software remote assistance.

Try to discover if the machine is acquiring an IP Address, after that you can discover what's happening, just look at the router or server of your network and open the case to see if everything is connected, there is a cable inside of the case, that it's extending the Pi Board to the LAN Network Port of the case, this is not difficult.


Just to clarify the web Interface won't come up at all. I think the IP configuration Is incorrect. So I'm not able to do any reset, reboot or other options in the web interface




If anybody could lead some help that would be great. Would be willing to pay to get this figured out and working
[[
[/QUOTE]


Vagnavs

New Member
Jul 13, 2017
5
2
3
41
Hi,
Double check that the network cables inside the miner is securely connected. If everything is good and you are still not able to find the IP address, it sounds like a corrupted sd card. You will need to re-image it with the file mentioned in ottokoester's post above.
I'm assuming it is a Incorrect IP configuration. I tried to set a static and can't remember the static. I've looked through everything as far as finding the device on the network. I think I'll go the microSD card reimage route. Just wondering how best to burn the contents? I'm used to ISO, not so much IMG And on Windows 7

I did find the Win32 Disk imager. But didn't know if you had some recommendations instead

Last edited:

iBeLink_1

Active Member
Feb 17, 2016
382
65
98
I'm assuming it is a Incorrect IP configuration. I tried to set a static and can't remember the static. I've looked through everything as far as finding the device on the network. I think I'll go the microSD card reimage route. Just wondering how best to burn the contents? I'm used to ISO, not so much IMG And on Windows 7

I did find the Win32 Disk imager. But didn't know if you had some recommendations instead
Hi,
I believe IMG and ISO are pretty similar. You can follow the same procedure in burning an ISO and use it with the IMG. I used the Win32 Disk imager which is easy to use.


Vagnavs

New Member
Jul 13, 2017
5
2
3
41
Thanks everybody for your help in getting my miner back up and running! ibelink product and support have been great..

  • Like
Reactions: iBeLink_1

saurabh gautam

New Member
Aug 28, 2017
1
0
1
35
Hi all , i ve rcvd my iBeLin DM11G X11/Dash Miner from mainminers websites but it gets over heated ..did any one else have the same issue or did i get a faulty item ?? bcz it is still in the warranty ...please please reply me ASAp before my warranty gets over


iBeLink_1

Active Member
Feb 17, 2016
382
65
98
Hi all , i ve rcvd my iBeLin DM11G X11/Dash Miner from mainminers websites but it gets over heated ..did any one else have the same issue or did i get a faulty item ?? bcz it is still in the warranty ...please please reply me ASAp before my warranty gets over
Hi,
Can you explain what you mean by overheat? Our miners will adjust the PLL (clock setting) lower when a temperature of 38C is detected. Also, please update firmware to IB3.5.25. You can do that from the Config page at the bottom. Check the box next to Update and hit the "Update" button.


China911

New Member
Sep 10, 2017
1
0
1
36
If you are intereted in buying this ASIC you can add my Wechat (+8613710222416) i am in China.


Rabinovitch

Member
Mar 29, 2016
103
13
68
Has anyone real experience of mining with DM11G? I know that DM384M was sucks. These new miners should also be sucks. Are they?


mrearthbound

Member
Feb 18, 2017
248
44
88
32
Yes, the DM11G also do suck. Loud as hell, too clunky and 2 of the ones I received are working at ~80% capacity. I'll need to RMA 1 of the 4 blades that come with it. I actually have to look for a warehouse to put these damn things because they're just too loud to have in my house. Really disappointed.
